500kg induction furnace for smelting different metals

Author : Hongteng Time: 2022-04-24

The 500kg induction furnace is usually a melting furnace with a furnace body capacity to melt 500kg of scrap steel. For the smelting of different metals, due to the different specific gravity of the metal, the same 500Kg metal has different volumes, so the outer dimensions of the smelting furnace body are different, and the size of the induction coil is also different.

When we choose the 500kg induction furnace that suits us, we must figure out what the material of the smelting metal is, otherwise, the smelting effect will be very different, which will affect the production capacity. Today, Luoyang Hongteng editor will introduce it to you.

1. Differences in the furnace body

The capacity of alloy steel, alloy aluminum and alloy copper melting furnaces are all 500Kg, and the furnace bodies are different. Taking alloy steel as the standard, the furnace body of 500Kg aluminum alloy melting furnace is equivalent to the furnace body of 1500Kg alloy steel; The 500Kg alloy copper smelting furnace body is only equivalent to the 850Kg alloy steel furnace body.

2. Difference in melting temperature

The melting temperature of 500kg alloy steel melting furnace is generally 1650 degrees; the melting temperature of 500kg alloy aluminum melting furnace is generally 800 degrees; the melting temperature of 500kg copper melting furnace is generally 1200 degrees;

3. Difference of smelting power of 500kg smelting furnace

Calculated by melting a furnace of metal in one hour, the smelting power of a 500kg smelting furnace is still different. The melting power configuration of the 500kg alloy steel melting furnace is 350Kw; the melting power configuration of the 500kg alloy aluminum melting furnace is 250Kw; and the melting power configuration of the 500kg alloy copper melting furnace is 300Kw.

4. Difference of 500kg smelting furnace body coil

The size of the induction coil for smelting steel, smelting aluminum and alloy copper copper is different, the diameter is the same, and the number of coil turns is also different.

Luoyang Hongteng can customize suitable melting furnaces for users according to their needs. Welcome to follow us and let us provide you with more electric furnace services.

Video of the use process of the melting furnace
